Well equipped galley with induction cooking, microwave/oven, 3 fridge/ freezers, Cooker, dishwasher and fresh (sparkling) water filtration system ensures that her guests do not have to miss out on anything.

These comfort features are further supported by a generator, air-conditioning system, ample hot water (80l) as well by her watermaker (Schenker 100l/hr).

For rainy (fully enclosed) or overly sunny days a bespoke and easily stowable bimini system that attaches to the sprayhood can be set up to protect her guests from the elements.

Once in racing mode, her light and stiff build allows her to outpace competition in the Mini-Maxi class.

2025 December – all standing rigging was checked in Future Fibres and install again. Hull bottom has been repainted, including all coating layers. New antifouling has been applied.

GENERAL DATA

MAST

Mast and boom are built in carbon fibre by Hall Spars. The construction of the mast is hybrid modulus monolithic type laminated seamlessly over a male mould.

SAILS

MAIN ENGINE

Main engine is a Yanmar 4-cylinder, turbocharged, intercooled, diesel, with a power output of 110 hp (80.9 kW)

WINCHES

There are four (4) Harken winches onboard, all of which are accessible from the cockpit:

• Primary (2) x Harken 990.3 with CFRP crowns
• Mainsheet (1) x Harken 70.3
• Secondaries (2) x Harken 60.3

ELECTRONICS

Navigation Station

• 15” monitor with integrated navigation and monitoring computer
• B&G remote VHF handset
• B&G V60 VHF transceiver
• 10” C-Zone touch screen monitor (control & monitoring)

Port Helm

• B&G Zeus³ 7” chart plotter
• B&G H5000 FGD (Full Graphic Display)

Starboard Helm

• B&G Zeus³ 7” chart plotter
• B&G H5000 FGD (Full Graphic Display)
• B&G H5000 autopilot controller

Mast Instrumentation

• 2 × B&G Nemesis 7” FGD displays (installed at the mast)

Captain’s Cabin

• B&G Vulcan 7” chart plotter (without radar)
• C-Zone 5” touch screen monitor

Master Cabin

• B&G Vulcan 7” chart plotter

HYDRAULIC SYSTEM

A hydraulic system is installed for tensioning of the mainsail outhaul, vang, backstay, and inner forestay via Bamar cylinders

WATERMAKER

The water-maker is a Schnenker Modular 100 which operates at 24-VDC. (90L/min)

GENERATOR

MASE variable speed generator. The model is VS6.5. The rated output is 6 kW at 230-VAC – 50 Hz

HEATING / AIR CONDITIONING

The vessel’s interior is air-conditioned throughout by means of a chiller type system by “Climma” with a total capacity of 32,000 BTU

ENTERTAINMENT

A 32″ Samsung flat screen smart television is installed on a power lift.

SAT COM

Starlink is instaled.

Price: USD 2,900,000

Specifications cont’d

As per standard Y7 specification (see attached) with the following equipment / options:

INTERIOR DESIGN / ACCOMODATIONS

Y7 Layout 3: Owner’s cabin with en-suite bathroom in bow. Salon incl. galley and dining area on STB, lounge area on PS. Double cabin with en-suite bathroom on PS. Chart table facing outboard on STB. 2 x twin guest cabins with en-suite bathrooms aft. Crew cabin with twin bunk, en-suite bathroom and separate companion way aft.

Light weight interior with hand brushed, white oak furniture and chrome detailing. Salon upholstery by Poltrana Frau.

INTERIOR RENDERINGS

KEEL

Custom telescopic shallow draft keel by APM Telescopic keel with lead bulb and temperature sensors for hydraulic system, including alarm function. The boat is also equipped with an additional hydraulic power pack in order to support the telescopic keel and furling V boom.

MAST AND RIGGING

See attached standard Y7 specifications. In addition, the following options/upgrades have been added:

• Hydraulic mainsheet trimmer. Carbon furling AXXON V boom, instead of standard boom.
• In-boom manual dinghy system using carbon arm and hoisting mechanism.
• Code 0 system, including BAMAR electric furler, 2:1 halyard system, 1:1 halyard system for gennaker, sheets, blocks and padeyes.
• RECKMANN hydraulic jib furler, FUTURE FIBERS inner jib luff cable Foghorn at 1st spreader.
• Spreader LED lights, 6 x up and 2 x down.

PROPULSION AND POWER GENERATION

See attached standard Y7 specifications. In addition, the following options/upgrades have been added:

• MAX POWER VIP250HYD hydraulic, retractable bow thruster securing approx. 13.5 kW / 18.1hp thrust
• MAX POWER VIP 250SP electric 24V, retractable stern thruster securing approx. 15 kW / 20 hp thrust, including extra charger and battery bank (200 Ah).
• NIMEA interface to visualize NANNI engine data on plotter display
• AC power pack upgrade: Generator FISCHER PANDA 19i PMS, 230 V /50 Hz, 18.8 VA / 15.0 kW, including battery pack upgrade to 1,200 Ah, 24 V DC with 2nd 75 Ah, 24 V alternator on 2nd engine
• 10kw Shore Power Converter

COMFORT

See attached standard Y7 specifications. In addition, the following options/upgrades have been added:

• MIELE washer/dryer combo installed in stbd guest cabin
• MIELE dishwasher in galley, 230 V

COMFORT cont’d

• MIELE cooker hood in galley 230 V
• MIELE 4 zone gimballed induction hob, including oven with microwave function 230 V, upgrade from standard gas cooker and oven
• Stainless steel ISOTHERM refrigerator drawer in cockpit, approx. 30 l
• Additional stainless steel VITROFRIGO refrigerator drawer in galley, approx. 70 l
• Wine cooler, approx. 62 l, 20 bottles
• FRIGOMAR air conditioning with central chiller unit system, approx. 62,000 BTU controllers and outlets
• SCHENKER Smart 100 watermaker, 24 V, 100 l /h
• Lee cloths for each berth / Full complement of linens

ENTERTAINMENT

• SONOS music system, 4 German Maestro speakers in salon, 2 German Maestro speakers in cockpit
• Wifi Router, plus 5G internet antenna
• FRAME TV on bulkhead in salon
• APPLE TV

ELECTRONICS

B&G navigation package, including:

• 1 x B&G Zeus3 12’ multifunction display at chart table
• 2 x B&G Zeus3 16’ multifunction display, one at each steering station
• 2 x B&G Triton 20/20 large graphic display, one at each cockpit coaming
• B&G CPU Hydra computer
• B&G H5000 autopilot, including pilot keyboard at stbd steering console
• B&G NAIS Class B transponder
• B&G V90 VHF radio at chart table, including H50 handheld at stbd steering console
• B&G broadband Halo 20+ radar mounted on spreader
• 2 x B&G Nemesis 12’ large graphic display mounted on mast bracket on mast
• 24’ Zeus Glass Helm in lieu of 16’ Zeus chartplotter
• Starlink / cellular wifi system
• PREDICTWIND data hub

HULL AND DECK

See attached standard Y7 specifications. In addition, the following options/upgrades have been added:

• Hull painted with PU coating in light unicolor (Sky Blue) instead of standard finish
• Coach roof painted with PU coating in light unicolor (Matterhorn White) instead of standard finish
• Underwater lights at stern, RGB (3 x 4 pcs)
• ELECTRO SEA seawater treatment system to keep strainers clean
• BRIG FALCON 360HT inflatable tender with 30 hp Suzuki outboard which fits in aft tender garage
• Viking 6-person life raft

DECK EQUIPMENT

See attached standard Y7 specifications. In addition, the following options/upgrades have been added:

• Deck wash system using fresh water, including spray hose, located in anchor locker
• Shore freshwater connection with pressure reducer
• 2 x HARKEN B80.3STEA electric primary winch (instead of standard electric 80.2STEA)

DECK EQUIPMENT cont’d

• 2 x HARKEN B80.2STEA electric secondary winches (instead of standard manual 80.2STA)
• Ultralight FENDERTEX fenders
• Misc. extra halyards, sheets / full complement of tools and misc. spare parts / second anchor

SAILS

• 3Di Ocean Full Batten Square Top mainsail w/ C-TECH carbon fiber battens
• 3Di Ocean Roller Furling, Self Tacking jib
• 3Di Ocean Furling Genoa Staysail
• Code 75 Furling Reacher, 3 oz polyester fabric
• Furling Gennaker, 1.5 oz Norlon fabric

EXTERIOR CANVAS

• Sprayhood with stainless steel frame
• Cockpit canopy including 4x SEASMART carbon poles
• Helmsman canopy including 4 x SEASMART carbon poles
• Cockpit cushions in SUNBRELLA fabric
• Boom and cockpit sunshade

SPECIAL OPTIONS

• Sunbed aft of cockpit tables with matching cushions
• Cupholders: 2 in cockpit tables, 4 in coamings, 2 near helms
• 2 hatches in Owner’s Cabin instead of 1
• 4 hatches in Salon Roof instead of 2
• Interior hull side panels in Salon in Alcantara fabric
• Additional bookshelves/cabinetry in Salon

ADDITIONAL INFORMATION

2023 Winner of “Best Sailboat” at the Newport International Boat Show

Shipyard / Interior Design:
Michael Schmidt Yachtbau, dba YYachts, Germany

Naval Architect/Exterior Designer:
Tripp Design Naval Architecture, USA and The Netherlands

Structural Engineering: AMS, Italy

Arcturus is hull n. 17 of Y/Yachts Shipyard’s successful Y7 series. She was created in collaboration with US designer Bill Tripp, who is responsible for her contemporary and minimalistic design.

This carbon-built lightweight sailing yacht combines performance, relaxed cruising, and sophisticated comfort—appealing to the discerning buyer seeking both quality and elegance.

Like many fast-sailing yachts, Arcturus features a wide stern equipped with a twin rudder, while the two Nanni 80hp engines ensure excellent handling, even in marinas.

Her light displacement (just 29 tons) and nearly 300 m² of sail area keep the Y7 moving even with little wind. Thanks to her excellent maneuverability, she is perfect for an owner/operator or small crew, making her ideal for cruising with family or a small group of friends.

Her welcoming and sophisticated interior is built from veneer and lightweight materials. She accommodates 6 guests in 3 well-conceived cabins.

LAYOUT

ACCOMMODATIONS & ARRANGEMENT

Main Salon

• Wide, light, and open-plan with wrap-around glass.
• L-shaped sofa on port side.
• L-shaped dining 3-seater bench on starboard side (instead of linear sofa).
• Chart table in starboard corner.
• Open office area next to the exposed mast.
• Open galley on starboard side.
• Natural oak wood finishes.

Master Cabin

• Located forward with centerline bed and walkways on both sides.
• Access to forward heads and shower.
• Wardrobe plus large vertical storage lockers in both corners.
• Natural oak wood finishes.
• Emergency exit through overhead hatch.

Guest Cabins

Starboard Twin

• Twin beds with vanity desk.
• Washing machine in cupboard.
• Wardrobe, locker space, and overhead storage.
• En suite head and shower.
• Exterior portholes, including portholes to cockpit area.

Port Twin

• Two single beds with locker space.
• Access to crew cabin.
• Exterior portholes, including portholes to cockpit area.

Crew Accommodation

• Two bunks with heads and integrated shower.
• Crew entrance/exit hatch.
• Access via Port Twin cabin.

MECHANICAL & ELECTRICAL EQUIPMENT

NAVIGATION & COMMUNICATIONS

• 1 × B&G Zeus3 12″ multifunction display at chart table
• 2 × B&G Zeus3 16″ multifunction displays (one at each steering console)
• 2 × B&G Triton 20/20 large graphic displays (one at each cockpit coaming)
• B&G CPU Hydra computer
• B&G H5000 autopilot incl. pilot keypad at starboard steering console
• B&G NAIS Class B transponder
• B&G V90 VHF radio at chart table incl. H50 handheld at starboard steering console
• B&G Broadband Halo 20+ radar mounted on spreader incl. bracket
• 2 × Nemesis 12″ portrait displays, Nemesis Hub and custom mast bracket
• LTE active antenna on Spreader 3 (painted black) with WLAN router & repeater
• Oscar collision avoidance system

MAST & RIGGING

• Carbon mast, AXXON
• Carbon furling V boom AXXON (instead of standard boom) incl. RECKMANN “FurlFind” system
• Mast and boom in clear coat carbon
• Predisposition for storm jib stay: padeye on deck, mast reinforcements and outlets, 2:1 purchase on halyard, 2 blocks for sheets
• 2 × Kevlar running backstay systems
• Code 0 system incl. Bamar electrical furler
• Spreader lights on mast – 6 × upward and 2 × downward

DECK EQUIPMENT

• Deck wash system with 2 connection points
• Shore freshwater connection with pressure reducer
• HARKEN CLR retractable mooring winch, 24 V, 2,000 W flush mounted at foredeck
• Deck surfaces covered with premium natural teak, 55 mm wide planks, light grey caulking
• Rocna Vulcan 40 kg anchor
• 125 m stainless steel anchor chain Ø 12 mm
• 2 × carbon steering wheels
• Carbon gangway
• Cockpit table convertible into sunbed position with additional Sunbrella cushions
• Coach roof cushions in Sunbrella
• Sprayhood with stainless steel frame
• Cockpit bimini fixed with stainless steel frame and fabric cover incl. 4 × SEASMART carbon poles
• Cockpit cushions in Sunbrella
• Sun awning & protection covers set: sunshade awning with rails on boom, mesh for windows, boom cover/lazy bag, 2 × steering pedestal and wheel covers, 2 × cockpit table covers, 4 × storage bags for winch handles
• 2 × HARKEN B80.3STEA electric primary winches
• 2 × HARKEN B80.2STEA electric secondary winches

ENTERTAINMENT EQUIPMENT

• Sonos audio system with 2 speakers in saloon + 2 portable units
• Sat TV preparation in mast, 4G internet
• Sony 43″ TV incl. TV lift in saloon

GALLEY & LAUNDRY EQUIPMENT

• Miele washer/dryer combo
• Miele dishwasher
• Miele cooker hood
• Miele 4-zone induction hob + oven with microwave
• Stainless steel Isotherm refrigerator drawer in cockpit, approx. 30 l, 24 V
• Grohe Blue system in galley
• Isotherm fridge in cockpit, 30 l
• Vitrifrigo wine cooler (20 bottles)
• Vitrifrigo fridge with two drawers, 182 l

DOYLE SAILS

• Furling mainsail
• Self-tacking jib
• Inner forestay jib
• Code 0
• Gennaker

Gallery – Interior

Gallery – Exterior

LAYOUT

SPECIFICATIONS

STANDARD BOAT
– Y8 as per standard specification.
– Light-weight Interior in natural oak incl. detailing in chrome finish.
– Carbon Hull and Deck, Carbon Mast and Boom.
– Deck surfaces and cockpit covered with synthetic teak

INTERIOR DESIGN
– Mahogany style furniture and fooring 1
– Upgrade fittings from chrome to satin finish (not all small parts possible) 1
INTERIOR ACCOMMODATION
– Y8 STANDARD LAYOUT: Owner’s cabin with en-suite bathroom with wardrobe in the front area.
Big salon lounge area incl. dining area fwd, furniture to be chosen by option Y8.02141 – 145.
2x double guest cabins with en-suite bathrooms.
Crew area in the aft with separate entrance and galley, crew mess and
1x twin bunk crew cabin in the aft with en-suite bathroom

INTERIOR
– Seating furniture preselection Berlin style. Only in combination with standard layout 1 1
KEEL
– T-shaped fixed shallow keel with WELDOX fin securing lower centre of gravity with lead bulb, 3.7m

MAST & RIGGING
– Carbon mast and boom AXXON painted in white, RAL 9010 or clear coat (instead of standard black)
– HARKEN switch track, 32mm for easy mainsail storage 1
– Additional HARKEN track for trysail on mast 1
– V boom from AXXON

ENTERTAINMENT

Entertainment Package Y8 1

• Peplink 5G router installed at 2nd spreader, with SIM Card exchange
  and 3 WiFi Access points installed under deck
• Sound System in salon: Sonos AMP x2 ; Sonance VP 68 rect. Speakers 4x in main salon
• Cockpit Sound Package: Sonance VPXT6R 2x ; Sonos AMP x1

ELECTRONICS
B&G Navigation package Y8 1

• B&G Zeus3S 12″ multifunction display, at chart table
• 2 x B&G Zeus3S 16″ multifunction display, one at each steering console
• 2 x B&G Nemesis 9″ plus Nemesis controller, one at each cockpit coaming
• B&G Triton Edge processor
• B&G H5000 autopilot incl. pilot keypad at stbd steering console
• B&G NAIS Class B transponder
• B&G broadband Halo 20+ radar mounted on spreader incl. bracket
• B&G V100 VHF radio at chart table incl. H60 handheld at stbd steering console

MOORING & DOCKING
Mooring package Y8 1

• Anchor windlass control incl. chain counter at remote control Y8
• 4 x mooring lines, black (2x 15m and 2x 20m, 20mm)
• 8 x inflatable fenders, incl. fender socks and lines, compressor in Lazarette
• Boat hook
• Stainless-steel Ultra 60 kg, anchor (instead of standard anchor) Y8
• Stainless-steel chain, 100m, 12mm (instead of standard chain)
• 2 x shore power cable, 25m
• Carbon flagpole
• Supports for bathing ladder usable as side-boarding ladder
  for easy access to pontoon+swimming ladder
• Storage unit in sail locker
• Storage unit in lazarette

MISCELLANEOUS
Delivery package Y8 1

• Preliminary calibration of the instruments
• Export documents
• Launching in Greifswald, Germany
• Mast stepping and rig trimming
• Hull bottom treatment: HEMPEL 2 coats of primer and 3 coats of antifouling
• 3 x days instruction of boat, explanation of systems and electronics with skipper

EXTRA

• Flush high load padeyes 1
• High gloss finish for cockpit and enterance 1
• Set of doyle sails, Jib, Main and code zero 1
• 2x Genaker, 1x blue 1x red 1
• Dinghy 3.7m with 15HP outboard

Gallery – Interior

Gallery – Exterior
